With the increasing global demand for energy efficiency and environmental protection, heat pumps are becoming more and more popular with home users as an energy-efficient device. Proper installation is essential to ensure the efficient operation of a heat pump system. This article will provide you with a detailed introduction to the installation of domestic heat pumps, as well as key points to note, to help you complete the installation of heat pumps and ensure the long-term stable operation of the equipment.

1. Preparation before installation

Before installing the heat pump, first of all, you need to carry out some necessary pre-preparation work:

Choose the installation location

The indoor unit should usually be installed in a well-ventilated place, avoiding direct sunlight and obstructed airflow. Outdoor units need to be installed in an open space to ensure air circulation and to avoid possible noise disturbance to neighbors. Outdoor units should be installed at a certain distance from the ground to prevent water or ice from accumulating and affecting the operation of the unit.

Check the power supply and electrical system.

Ensure that the home electrical circuit meets the voltage requirements of the heat pump unit. Power access to the heat pump must be done by a professional electrician to ensure compliance with safety standards.

Measure the space dimensions.

Ensure that the indoor and outdoor installation space is sufficient to not only accommodate the equipment but also provide the required ventilation space for the proper operation of the equipment.

2. Installation of outdoor unit

The outdoor unit usually needs to be installed on the outside of the building to ensure good ventilation. The following are the installation steps:

Mounting bracket or platform

Choose a flat, sturdy surface on which to place the outdoor unit. Use brackets to secure the outdoor unit to the floor or wall to avoid vibration and noise. Make sure the bracket is stable to prevent wind or other external forces from affecting the stability of the unit.

Connecting pipes and cables

Use professional tools to connect the refrigerant pipes, power supply cables, and control signal cables. Make sure that the piping is firmly connected and free of leaks, and avoid excessive bending of cables and piping.

Drainage pipe installation

If the appliance has a drainage function (e.g. condensate drain), make sure the drainage pipe is smooth to avoid blockage.

3. Installation of indoor unit

The installation location of the indoor unit is usually chosen on the wall of the living room or bedroom to ensure that the hot air can be evenly distributed. Installation steps include:

Install the bracket and fix the indoor unit

Drill holes in the wall and install the bracket, then fix the indoor unit to the bracket. Ensure that the position of the indoor unit is securely fixed and that the pipework between it and the outdoor unit is smoothly connected.

Connecting pipes and electrical wiring

Connect the refrigerant piping between the outdoor unit and the indoor unit and ensure that the electrical wiring meets safety standards. For complicated electrical connections, it is recommended that an electrician carry out the operation.

4. Refrigerant Charging and System Testing

Vacuuming and Fluorine Charging

After the installation is completed, a vacuum pump must be used to evacuate the air and moisture in the system to ensure that it is clean and free of impurities internally. Then, according to the requirements of the heat pump manual, the appropriate amount of refrigerant must be charged into the system.

Test the system for fluorine leakage.

After charging the system with fluorine, the professional should check the system for leaks using a pressure test and a leak detection tool. If any problems are found, they should be repaired immediately.

5. Electrical wiring and control settings

Connect the power supply and check the control system

Ensure the heat pump is properly wired for power and set the thermostat or control panel. Ensure that the indoor thermostat can properly control the operation of the indoor unit and set the proper temperature.

Commissioning and system verification

Switch on the power and start the heat pump to check that the heating and cooling functions are operating correctly. Make sure all equipment components are working as expected.

Summing Up

Proper heat pump installation improves the equipment's efficiency and extends its service life. By choosing the right installation location, ensuring that the system is properly connected, charging the fluorine promptly, and checking the equipment's operating status, you can ensure the long-term stable operation of your heat pump system. If you are unfamiliar with the installation process or encounter complicated problems, it is recommended that you hire a professional to carry out the installation and commissioning.
